When installing the indoor bus cable, you should also remember the following boundary
conditions (d
A
= outer diameter of the cable):
Table 6-2 Boundary conditions for indoor routing of bus cable
Features General conditions
Bending radius for a single bend ≥ 80 mm (10 × d
A
)
Bend radius for multiple bends ≥160 mm (20 × d
A
)
Permissible temperature range for installation - 5° C to + 50° C
Temperature range for storage and stationary op‐
eration
- 30° C to + 65° C
Note
The length codes for the pre-assembled cables can be found on the website
www.siemens.com/simotion (www.siemens.com/simotion).
6.6 Connecting Ethernet
Procedure
Plug the LAN cable into the Ethernet interface of the SIMOTION P320‑4. You must hear the
connection engage properly.
Cables
Standard shielded twisted pair cables are used for the networking in this case.
The following connection cables are recommended:
● SIMATIC NET, ind. Ethernet TP XP CORD RJ45/RJ45, TP CORD assembled with 2 RJ45
connectors, send and receive cables crossed (cross-over)
Order no.: 6XV1850-2H*)
● SIMATIC NET, ind. Ethernet TP CORD RJ45/RJ45, TP CORD assembled with 2 RJ45
connectors
Order no.: 6XV1850-2G*)
*) Length code Dimensions
E50 0.5 m
H10 1 m
H20 2 m
H60 6 m
N10 10 m
Connection
6.6 Connecting Ethernet
SIMOTION P320-4 E / P320-4 S
112 Commissioning and Hardware Installation Manual, 11/2016
