Note
LEDs for IsoPROFIBUS board
The LEDs BUS1F and BUS2F are only shown if an IsoPROFIBUS board is connected.
Additional references/information
You can find additional information at:
● Diagnostics via LED displays (Page 193) (for a more accurate diagnosis of an LED state)
● Operating displays (SIMOTION P320-4 E / P320-4 S Manual: Information on display
modes, of the SF PROFINET LEDs only displayed on the hardware side, in the operating
displays section)
● PROFINET bus error occurs (Page 199)
8.1.3 Mode selector
Mode selector in SIMOTION P State
Use the mode selector to set the SIMOTION P320-4 to different states. The controller can be
switched in RUN or STOP / STOPU mode and perform an overall reset.
The change of the operating state with the mode selector has priority over a state selected via
SIMOTION SCOUT.
Note
Setting the operating state via the mode selector
The STOP/STOPU switch position cannot be set to RUN via the SIMOTION SCOUT.
To change the operating state, use the mode selector.
Further information
Further information can be found in Section Overall reset with the mode selector (on the
screen) (Page 174).
Operator Control (hardware)
8.1 SIMOTION P state application
SIMOTION P320-4 E / P320-4 S
Commissioning and Hardware Installation Manual, 11/2016 121
