NOTICE
Observe UL508
For use in the area of Industrial Control Equipment (UL508), remember that
SIMOTION P320-4 is classified as Open type.
Installation of the device in an enclosure according to UL508 is conditional for approval or
operation according to UL508.
Types of installation
The following SIMOTION P320‑4 installation types are permitted and described in the following
sections:
● Standard rail mounting (Page 88)
● Vertical mounting (Page 91)
5.6.2 Standard rail mounting
Mounting the SIMOTION P320-4 on a standard rail
Note
Use of Siemens 35 mm standard mounting rail is recommended.
Mounting the standard mounting rail clip
Before you can install the device on a standard mounting rail, you will need to attach the
standard mounting rail clip included in the scope of delivery.
The fasteners and screws required are supplied with the device for mounting depending on
the order number.
Requirement
● 1 standard mounting rail clip
● 2 screws
● 1 T20 screwdriver
Use the two screws to mount the standard mounting rail clip on the SIMOTION P320-4
enclosure.
Mounting
5.6 Installing the SIMOTION P320-4 in the control cabinet
SIMOTION P320-4 E / P320-4 S
88 Commissioning and Hardware Installation Manual, 11/2016
