,2
GULYHV
,2
GULYHV
+0,(6
352),%86'3
352),1(7,2
6,027,213
Figure 3-5 Model: Local HMI or ES
Alternatively to TCP/IP , SIMOTION SCOUT can also communicate locally via PC internal
(local) .
Figure 3-6 Set PG/PC Interface - PC internal (local) dialog box
3.3.2.1 Setting up a network bridge - MAC bridge miniport
Note
If you are working with SIMOTION P320-4 version V4.5, the Network Bridge is already preset.
The network bridge is not preset for version V4.4 and must be set up as described in the
following.
The following is a step-by-step description of how the network bridge MAC Bridge Miniport is
set up.
Description
3.3 HMI and SIMOTION SCOUT
SIMOTION P320-4 E / P320-4 S
Commissioning and Hardware Installation Manual, 11/2016 61
