Siemens SINAMICS G120 User Manual

Parameters
Introduction to Parameters
1-14
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
Table 1-4 Unit group (p0505)
Unit group Unit selection for p0505 = Reference value
at %
1234
2_1 Hz % Hz % p2000
3_1 rpm % rpm % p2000
5_1 Vrms % Vrms % p2001
5_2 V % V % p2001
5_3 V % V % p2001
6_2 Arms % Arms % p2002
6_5 A % A % p2002
7_1 Nm % lbf ft % p2003
7_2 Nm Nm lbf ft lbf ft -
14_5 kW % HP % r2004
14_10 kW kW HP HP -
21_1 °C °C °F °F -
21_2 K K °F °F -
39_1 1/s
2
%1/s
2
% p2007
Table 1-5 Unit group (p0595)
Unit group Unit selection for p0595 = Reference value
at %
Value Unit
9_1 The values that can be set and the technological units are shown in
p0595 (see Chapter 1.2).
Table 1-6 Unit group (p11026)
Unit group Unit selection for p11026 = Reference value
at %
Value Unit
9_2 The values that can be set and the technological units are shown in
p11026 (see Chapter 1.2).
Table 1-7 Unit group (p11126)
Unit group Unit selection for p11126 = Reference value
at %
Value Unit
9_3 The values that can be set and the technological units are shown in
p11126 (see Chapter 1.2).

Siemens SINAMICS G120 Specifications

General

Power Range	0.37 kW to 250 kW
Output Voltage	0 V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Enclosure Rating	IP20, IP21, IP55
Control Modes	V/f control, vector control, servo control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling Method	Air cooling
Input Voltage	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
