Siemens SINAMICS G120 User Manual

Function diagrams
Input/Output Terminals
2-512
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.4 Input/Output Terminals
Function diagrams
2220 – Digital inputs, electrically isolated (DI0 ... DI5) 2-513
2222 – Analog inputs as Digital inputs (DI11 ... DI12) 2-514
2230 – Digital outputs (DO0 ... DO2) 2-515
9566 – Analog inputs 0 ... 1 (AI0 ... AI1) 2-516
9568 – Analog input 2 (AI2) 2-517
9576 – Temperature evaluation Ni1000/PT1000 (AI3) 2-518
9572 – Analog outputs 0 ... 1 (AO0 ... AO1) 2-519

Siemens SINAMICS G120 Specifications

General

Power Range	0.37 kW to 250 kW
Output Voltage	0 V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Enclosure Rating	IP20, IP21, IP55
Control Modes	V/f control, vector control, servo control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling Method	Air cooling
Input Voltage	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
