Siemens SINAMICS G120 User Manual

Internal control/status words
Function diagrams
2-549
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.6 Internal control/status words
Function diagrams
2501 – Control word, sequence control 2-550
2503 – Status word, sequence control 2-551
2505 – Control word, setpoint channel 2-552
2510 – Status word 1 (r0052) 2-553
2511 – Status word 2 (r0053) 2-554
2512 – Control word 1 (r0054) 2-555
2513 – Control word 2 (r0055) 2-556
2520 – Control word, speed controller 2-557
2522 – Status word, speed controller 2-558
2526 – Status word, closed-loop control 2-559
2530 – Status word, current control 2-560
2534 – Status word, monitoring functions 1 2-561
2536 – Status word, monitoring functions 2 2-562
2537 – Status word, monitoring functions 3 2-563
2546 – Control word, faults/alarms 2-564
2548 – Status word, faults/alarms 1 and 2 2-565
2634 – Sequence control - Missing enable signals 2-566

Siemens SINAMICS G120 Specifications

General

Power Range	0.37 kW to 250 kW
Output Voltage	0 V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Enclosure Rating	IP20, IP21, IP55
Control Modes	V/f control, vector control, servo control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling Method	Air cooling
Input Voltage	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
