Siemens SINAMICS G120 User Manual

Explanations for the function diagrams
Function diagrams
2-499
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.2 Explanations for the function diagrams
Function diagrams
1020 – Explanation of the symbols (Part 1) 2-500
1021 – Explanation of the symbols (Part 2) 2-501
1022 – Explanation of the symbols (Part 3) 2-502
1030 – Handling BICO technology 2-503

Siemens SINAMICS G120 Specifications

General

Power Range	0.37 kW to 250 kW
Output Voltage	0 V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Enclosure Rating	IP20, IP21, IP55
Control Modes	V/f control, vector control, servo control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling Method	Air cooling
Input Voltage	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
