Quick commissioning (p0010 = 1)
1-492
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
When p0010 = 1 is chosen, p0003 (user access level) can be used to select the parameters
to be accessed.
At the end of the quick commissioning sequence, set p3900 = 1 to carry out the necessary
motor calculations and clear all other parameters (not included in p0010 = 1) to their default
settings.
p1080 Minimum speed 1 C(1)T
p1082 Maximum speed 1 C(1)T
p1120 Ramp-function generator ramp-up time 1 C(1)UT
p1121 Ramp-function generator ramp-down time 1 C(1)UT
p1135 OFF3 ramp-down time 2 C(1)UT
p1300 Open-loop/closed-loop control operating mode 2 C(1)T
p1500 Selecting the torque setpoint 2 C(1)T
p1900 Motor data identification and rotating
measurement
1 C(1)T
p2196 Torque utilization scaling 1 C(1,3)UT
p3900 Completion of quick commissioning 1 C(1)
Note
This applies only in Quick Commissioning mode.
Table 1-10 Quick commissioning (p0010 = 1), continued
Par.-No. Name Access level Can be
changed

Siemens SINAMICS G120 Specifications

General

Power Range	0.37 kW to 250 kW
Output Voltage	0 V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Enclosure Rating	IP20, IP21, IP55
Control Modes	V/f control, vector control, servo control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Operating Temperature	-10°C to +50°C
Cooling Method	Air cooling
Input Voltage	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
