9.9 Multiple plunge-cutting – CYCLE411
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
175
9.9 Multiple plunge-cutting – CYCLE411
Programming
CYCLE411(N_SITZ, X_SOLL, Z_ST, Z_END, UBL, B_ART, A_LU, A_SR, A_SL, A_FSL,
SLZ, FSZ, ZU_ART, BVU1, BVU2, F_PE, F_SR, F_SL, F_FSL, N_FR, MZ, KS, F_KS,
UWERK)
Parameter
Table 9- 5 Parameters of CYCLE411
Parameter Data type Meaning
N_SITZ INT Seat number
X_SOLL REAL Setpoint diameter (abs.)
Z_ST REAL Starting position in Z (abs.)
Z_END REAL Target position in Z (abs.)
UBL REAL Overlap
B_ART INT Machining type:
1=roughing
2=finishing+fine-finishing
3=roughing+finishing+fine-finishing
A_LU REAL Air allowance (incr.)
A_SR REAL Roughing allowance (incr.)
A_SL REAL Finishing allowance (incr.)
A_FSL REAL Fine-finishing allowance (incr.)
SLZ REAL Infeed amount for finishing (incr.)
FSZ REAL Infeed amount for fine-finishing (incr.)
ZU_ART INT Infeed
-1 = only on the left
0 = on both sides
1 = only on the right
BVU1 INT Dwell time at reversal point1
BVU2 INT Dwell time at reversal point2
F_PE REAL Feedrate for reciprocating in Z
F_SR REAL Feedrate for roughing
F_SL REAL Feedrate for finishing
F_FSL REAL Feedrate for fine-finishing
N_FR INT Number of sparking-out strokes
MZ INT Measurement control Yes=1/No=0
KS INT Acoustic emission sensor Yes=1/No=0
F_KS REAL Feedrate for air grinding [mm/min]
UWERK REAL Workpiece peripheral speed [m/min]
