Cycles
9.13 Reciprocating – CYCLE415
Cylindrical grinding
194 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
9.13 Reciprocating – CYCLE415
Programming
CYCLE415(N_SITZ, X_SOLL, Z_ST, Z_END, B_ART, A_LU, A_SR, A_SL, A_FSL, SRZ,
SLZ, FSLZ, ZU_ART, BVU1, BVU2, F_PE, FP_SL, FP_FS F_SR, F_SL, F_FSL, N_FR, MZ,
KS, F_KS, UWERK)
Parameter
Table 9- 10 Parameters of CYCLE415
Parameter Data type Meaning
N_SITZ INT Seat number
X_SOLL REAL Setpoint diameter (abs.)
Z_ST REAL Starting position in Z (abs.)
Z_END REAL Target position in Z (abs.)
B_ART INT Machining type:
1=roughing
2=finishing+fine-finishing
3=roughing+finishing+fine-finishing
A_LU REAL Air allowance (incr.)
A_SR REAL Roughing allowance (incr.)
A_SL REAL Finishing allowance (incr.)
A_FSL REAL Fine-finishing allowance (incr.)
SRZ REAL Infeed amount for roughing (incr.)
SLZ REAL Infeed amount for finishing (incr.)
FSLZ REAL Infeed amount for fine-finishing (incr.)
ZU_ART INT Infeed
-1 = only on the left
0 = on both sides
1 = only on the right
BVU1 INT Dwell time at reversal point1
BVU2 INT Dwell time at reversal point2
F_PE REAL Reciprocation feedrate for roughing
FP_SL REAL Reciprocation feedrate for finishing
FP_FS REAL Reciprocation feedrate for fine-finishing
F_SR REAL Feedrate for roughing
F_SL REAL Feedrate for finishing
F_FSL REAL Feedrate for fine-finishing
N_FR INT Number of sparking-out strokes
MZ INT Measurement control Y=1 / N=0
KS INT Acoustic emission sensor Y=1/N=0
F_KS REAL Feedrate for air grinding [mm/min]
UWERK REAL Workpiece peripheral speed [m/min]
