Automatic mode
6.3 Selection and start of a part program
Cylindrical grinding
84 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
6.3 Selection and start of a part program
Functionality
Before starting the program, make sure that both the control system and the machine are set
up. Observe the relevant safety notes of the machine manufacturer.
Operating sequence
Select Automatic mode by pressing the "Automatic" key on the machine control panel.
The Program Manager is opened. Use the "NC directory" (default selection) or "Customer
CF card" softkeys to enter the appropriate directories.
Figure 6-5 The Program Manager start screen
Place the cursor bar on the desired program.
Use the "Execute" softkey to select the program to be executed (see also "External
execution"). The name of the selected program will appear in the "Program name" screen
line.
([H
FXWH
