4.7 Manual grinding
Cylindrical grinding
54 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
4.7 Manual grinding
Functionality
This function is for grinding (precision grinding) with the handwheel. This function does not
require a workpiece program.
Operation
Manual grinding is done in "Jog" mode.
The input screen is opened.
Entry of parameters into the input screen for manual grinding (see figure below):
● T or D number
● Select reciprocating motion via toggle field.
The following reciprocating motions are possible:
– No function
– X axis infeed, no reciprocation
– Z axis infeed, no reciprocation
– Z axis infeed, reciprocation in X axis
– X axis infeed, reciprocation in Z axis
● Tool peripheral speed (m/s)
● Workpiece speed (rpm)
