Parameter Value
Temperature limits:
● Storage in acc. with EN 60721-3-1
● Transportation (in transportation packaging)
in acc. with EN 60721-3-2
● Operation in acc. with EN 60721-3-3
-25 °C ... 55 °C
-25 °C ... 55 ºC
0 ... 45 ºC (front)
0 to 55 °C (rear)
Cooling By natural convection
Climate class
● Storage
● Transportation
● Operation
1K3 in acc. with EN 60721-3-1
2K4 in acc. with EN 60721-3-2
3K5 in acc. with EN 60721-3-3
Condensation, spraying water, and icing Not permitted
Supply air Without aggressive gases, dusts and oils
Approvals CE, cULus
Dimensions:
● Width
● Height
● Depth
483 mm
155 mm
55 mm
Weight, approx. 2 kg
*) If the outputs for the illuminated pushbuttons (X53/X54) are loaded with the max. permissible current
of 0.3 A, this results in additional power consumption of 36 W. The total power consumption is then 50
W.
See also
Other values/standards: Application planning (Page 35)
7.1.6 Spare parts and accessories
Table 7-14 Spare part kits for machine control panel MCP 483C PN
Name Description Qua
ntity
Article number
Emergency Stop
button
22 mm actuating element, 40 mm mushroom
pushbutton, snap action with tamper protection,
latching, red, with holder, non-illuminated
1 3SB3000-1HA20
Contact block with 2 contact pairs (1 NO + 1 NC), 2-pin, screw
terminal (3rd contact pair can be additionally
connected)
1 3SB3400-0A
Set of keys Set of keys for machine control panel 10 6FC5148–0AA03–0AA0
Rapid traverse dial for 16-stage rotary switch 20 6FC5248–0AF30–0AA0
Rotary switch for
spindle
Spindle/rapid traverse override, electronic
rotary switch 1x16G, T=24, cap, knob, pointer,
spindle and rapid-traverse dials
1 6FC5247–0AF12–1AA0
Connectable components
7.1 MCP 483C PN
PPU
108 Manual, 01/2014, 6FC5397-2DP40-3BA3
