Name Designation Color Description
H5 DIAG2 Green Reserved
H6 OVTemp Red Overtemperature indication
Note
When the system is booting, LEDs H1, H2 and H3 are lit.
7.6.2 Mounting
Mounting
The I/O module is screwed with a mounting plate to the control cabinet wall in the control
cabinet. The module must be installed according to EN 60204.
WARNING
Protection against electric shock
A protective conductor must be connected using the grounding screw.
Mounting versions:
● Portrait mounting at the lateral strap of the mounting plate (2x M5 or M6 screws).
● Flat mounting at the rear wall of the mounting plate (4x M5 or M6 screws).
Connectable components
7.6 PP 72/48D PN
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 169
