Parameter Value
Jog key: Negative traverse direction
Jog key: Rapid traverse for jog keys and handwheel
Function keys 3 x: F1, F2, F3
Handwheel 100 S/R
Rated voltage for switching signals 24 V
Rated voltage for handwheel 5 V
5 V current consumption Approx. 90 mA
Handwheel signals RS 422
EMERGENCY STOP button 24 V, 2 A NC contact
Enabling buttons 24 V, 2 A NO contact
Safety class IP65 (in acc. with EN 60529)
Approvals CE
Temperature ranges
● Operation
● Storage/transport
0 ... 55 °C
-20 ... 60° C
Temperature change Within 1 minute max. 0.2 K
Permissible change in relative atmospheric
humidity in acc. with EN 60721-3-3, Class 3K5
Within 1 minute max. 0.1%
Dimensions:
● Width
● Height
● Depth
180 mm
90 mm
67 mm
Approx. weight 0.5 kg without connecting cable
Max. cable length 25 m
7.5.6 Spare parts and accessories
List of the spare parts
The following spare parts are available:
Item name Article
number
Can be used with 6FX2007-
-1AD03 -1AD13
6-pos. load-tap-changer with accessories 104899 X X
Emergency-Stop button 104900 X X
ZXE-104833 (3-position enabling button) 104901 X X
Protective cover and nut for ZXE 104902 X X
Connectable components
7.5 Mini handheld unit
PPU
164 Manual, 01/2014, 6FC5397-2DP40-3BA3
