7.4.4 Technical specifications
Handheld electronic handwheel
Parameter Value
Operating voltage 5 VDC ± 5%
Current consumption Max. 80 mA
Limit frequency 10 kHz
Number of pulses 100 S/R
Displacement of phase A to B, typical 90° electrical
Interface RS 422
Cable length Max. 25 m
Actuating force 4 Ncm
Speed Max. 1,000 rpm
Protection class I
Degree of protection in acc. with DIN EN 60529/
IEC 60529
IP65
Vibratory load
● Operation
● Transportation (in transportation packaging)
58 – 200 Hz: 10 m/s
2
9 - 200 Hz: 20 m/s
2
Shock load in acc. with IEC 68-2-27
● Operation
● Transportation (in transportation packaging)
100 m/s
2
, 11 ms, 6 shocks
300 m/s
2
, 6 ms, 6 shocks
Condensation, splash water, and icing Not permitted
Supply air Without aggressive gases, dusts, and oils
Operation:
● Applicable standard
● Temperature range
● Limits for relative humidity
EN 60721-3-3
0 ... 50 °C
5 ... 80 %
Storage:
● Applicable standard
● Temperature range
● Limits for relative humidity
EN 60721-3-2
-20 ... 50 °C
10 ... 95 %
Enclosure material Thermoplastic
Dimensions:
● Width
● Height
● Depth
160 mm
85 mm
67 mm
Weight 0.3 kg (without spiral connection cable)
Connectable components
7.4 Electronic handwheel
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 153
