7.3.4 Technical data
MCP Interface PN
Parameter Value
Input voltage 24 VDC
Power consumption, max.
● Board
● Handwheels
● Lamps
● LEDs
● Total
2.4 W
2 x 0.9 W
54 W (15 x 3.6 W)
4 W (80 x 0.05 W)
62.4 W
Dimensions
● Width
● Height
● Depth
242 mm
152 mm
36 mm
Weight 557 g
Safety class according to EN60204-1 III
Degree of protection according to EN 60529 IP00
Approvals CE, cULus
See also
Other values/standards: Application planning (Page 35)
7.4 Electronic handwheel
7.4.1 Description
Validity
The description applies to the following electronic handwheel:
Designation Interface Article number
Handheld electronic handwheel DC 5 V, RS 422 6FC9320-5DE02
The portable electronic handwheel is intended for use in conjunction with machines. A
magnetic bracket and spiral connection cable can be found on its enclosure. The magnetic
bracket (retaining magnet) enables the handwheel to be attached to metallic surfaces.
The portable electronic handwheel is an incremental encoder that generates signals according
to how the manually operated wheel is rotated. The handwheel's magnetic latching facility
Connectable components
7.4 Electronic handwheel
PPU
148 Manual, 01/2014, 6FC5397-2DP40-3BA3
