Parameter Value
Temperature limits:
● Operation in acc. with EN 60721-3-3
● Storage in acc. with EN 60721-3-1
● Transportation (in transportation packaging)
in acc. with EN 60721-3-2
0 ... 45 ºC (front)
0 to 55 °C (rear)
-25 °C ... 55 °C
-40 °C ... 70 ºC
Cooling By natural convection
Climate class 3K3
Condensation, spraying water, and icing Not permitted
Supply air Without aggressive gases, dusts, and oils
Approvals CE, cULus
Dimensions:
● Width
● Height
● Depth
310 mm
175 mm
54 mm with cable
29 mm without cable
Weight, approx. 1.2 kg
*) If the outputs for the illuminated pushbuttons (X53/X54) are loaded with the max. permissible current
of 0.3 A, this results in additional power consumption of 36 W. The total power consumption is then 50
W.
See also
Other values/standards: Chapter "Application planning (Page 35)"
7.2.6 Spare parts and accessories
Accessories and spare parts for MCP 310C PN
Name Description Amoun
t
Article number
Emergency-Stop
button
22 mm actuating element, 40 mm mushroom
pushbutton, snap action with tamper
protection, latching, red, with holder, non-
illuminated
1 3SB3000-1HA20
Contact block with 2 contact pairs (1 NO + 1 NC), 2-pin,
screw terminal (3rd contact pair can be
additionally connected)
1 3SB3400-0A
Sets of keys Set of keys (10 sets) for machine control
panel
1 set 6FC5148–0AA03–0AA0
Set of tensioners Tensioner set (9 items) for supplementary
components with 2.5 mm profile, length 20
mm
1 set 6FC5248–0AF14–0AA0
Connectable components
7.2 MCP 310C PN
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 127
