Technical data
8
PPU
Parameter Value
Input voltage 24 VDC + 20% / - 15%
Power consumption, max. 60 W
Power loss 28 W
Heat dissipation Open-circuit ventilation
Degree of protection in acc. with EN 60529 IP65 (with closed front cover)
IP20 (rear)
Protection class in acc. with EN 61800-5-1 III (DVC A, PELV)
Pollution degree in acc. with EN 61800-5-1 2
Approvals CE / cULus
Classification:
● Operation
● Transportation (in transportation
packaging)
● Storage (in transport packaging)
3M1 in acc. with EN 60721-3-3
2M3 in acc. with EN 60721-3-2
1M2 in acc. with EN 60721-3-1
Mounting position Vertical
Dimensions:
● Width
● Height
● Depth
PPU vertical:
● 310 mm
● 380 mm
● 105 mm
PPU horizontal:
● 483 mm
● 220 mm
● 105 mm
Weight, approx. 4.5 kg
See also
Further technical data for the PPU can be found in the following sections:
● Transport and Storage Conditions (Page 39)
● Operating Conditions (Page 40)
● Requirements for the power supply (Page 69)
Digital inputs/outputs:
● Technical data (Page 83)
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 225
