10 Probes and Biopsy Brackets
132 Basic User Manual
Biopsy
Bracket Model
Available
Probe Model
Available Biopsy Needle Application
NGB6V3 6V3 16G, 18G, 20G, 22G Intracavitary
NGB6V1 6V1 16G, 18G, 20G, 22G Intracavitary
NGBEC9-5 EC9-5 16G, 18G, 20G, 22G Intracavitary
10.2.2 Assembling the Biopsy Bracket
■ To Assemble the Surface Biopsy Bracket
Tube Holder
Fixing Bracket
Protrusion
Biopsy Guide Tube
Perform the following steps.
1. Wear sterile gloves.
2. Unfold the probe sheath, and apply an appropriate amount of coupling gel into the
sheath and onto the face of the probe.
3. Hold the probe and unroll the sheath onto the probe. Pull the probe sheath tightly over
the face of the probe to remove any wrinkles.
4. Align the biopsy bracket with the orientation mark of the probe.
5. Attach the biopsy bracket to the probe and apply four protrusions with firm pressure.
Ensure the biopsy bracket is firmly attached to the probe.
Orientation Mark
To Next Page
