2 System Overview
Basic User Manual 19
No. Name Description
37 Function
Keys
●
These six function keys corresponds to the menu items
located at the bottom of the screen.
●
Press it to select the corresponding menu item.
●
Rotate it to set the selected menu item.
2.3.6 Key Panel
1 102 3 4 5 96 7 8 11 12 1413
16
192021 18 17
15
Figure 2-7 Key Panel
No. Name Description
1 Esc Exit the System Settings screen or New Patient screen.
2 Help Reserved
3 F3
The function of this shortcut key can set through the
system. The screenshot storage is default functions. For
details, refer to Section 4.1.3 Save Settings.
4 F4
The function of this shortcut key can set through the
system. The image print is default functions. For details,
refer to Section 4.1.3 Save Settings.
5 3D Reserved
6
Activate quad-split screen display.
Switch among four images in quad-split display.
7 Reverse an image up or down.
