Sony XVS-9000 Service Manual

1-2. Location of Main Parts (XVS-9000)
1-2-1. Front and Rear Board
Slot # Rear
DVP-68 (Option)
CA-92
MIX-57 (Option)
MIX-57 (Option)
XPT-38
DVP-68 (Option)
XPT-38
VPR-129 (Option)
VPR-129A (Option)
CA-92A
MIX-57 (Option)
MIX-57 (Option)
MIX-57 (Option)
Not used in this slot
Not used in this slot
Not used in this slot
Not used in this slot
Not used in this slot
DVP-53A (Option) / DVP-68 (Option)
Not used in this slot
DVP-53A (Option) / DVP-68 (Option)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Front
XPT-38
Not used in this slot
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
Not used in this slot
Not used in this slot
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
Not used in this slot
Not used in this slot
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
Not used in this slot
Not used in this slot
CNI-45 (Option)
CNO-44 (Option)
CNI-45 (Option)
CN-4020
Not used in this slot
NET-42 (Option)
NET-42 / CNO-45 (Option)
NET-42 (Option)
NET-42 / CNO-45 (Option)
NET-42 / CNO-45 (Option)
NET-42 (Option)
NET-42 / CNO-45 (Option)
NET-42 (Option)
NET-42 / CNO-45 (Option)
NET-42 / CNO-45 (Option)
Front board
Board name Function Remarks
CA-92 Unit control/reference generator/GbE hub board XVS-9000
CA-92A Unit control/reference generator/GbE hub board XVS-9000
DVP-53A HD DME board XKS-8470
DVP-68 DME board XKS-8475
MIX-57 Mix/Effect board XKS-8210
VPR-129 Frame memory board XKS-8440
VPR-129A Format converter board XKS-8460
XPT-38 XPT + Multi viewer board XVS-9000
Rear board
Board name Function Remarks
CN-4020 External control board XVS-9000
CNI-45 12G-SDI Input board XKS-S9112
CNO-44 12G-SDI Output board XKS-S9167
CNO-45 100G output board XKS-C9121
NET-42 100G input board/NMI input board XKS-C9111, XKS-C9121/XKS-C9111N,
XKS-C9121N
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
1-2
