Sony XVS-9000 Service Manual

1-4. Location of Main Parts (XVS-7000)
1-4-1. Front and Rear Board
MIX-57A (Option)
MIX-57A (Option)
MIX-57A (Option)
DVP-53A (Option) / DVP-68 (Option)
DVP-53A (Option) / DVP-68 (Option)
4
3
2
CN-3807
Not used in this slot
VPR-129 (Option)
VPR-129A (Option)
13
12
1
Slot #
11
10
9
8
7
6
CA-92
OUT-38A
(Option)
OUT-38
XPT-38
Front
5
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNI-43 / CNI-44 / CNI-45A / NET-32 / NET-42A (Option)
CNO-43 / CNO-44A / NET-32A / NET-42B (Option)
CNO-43 / CNO-44A / NET-32A / NET-42B (Option)
CNO-43 / CNO-44A / NET-32A / NET-42B (Option)
CNO-43 / CNO-44A / NET-32A / NET-42B (Option)
CNO-43 / CNO-44A / NET-32A / NET-42B (Option)
Rear
Front board
Board name Function Remarks
CA-92 Unit control/reference generator/GbE hub board XVS-7000
DVP-53A HD DME board XKS-8470
DVP-68 DME board XKS-8475
MIX-57A Mix/Effect board XKS-7210
OUT-38 Output processor board XVS-7000
OUT-38A Output processor board XKS-8160
VPR-129 Frame memory board XKS-8440
VPR-129A Format converter board XKS-8460
XPT-38 XPT + Multi viewer board XVS-7000
Rear board
Board name Function Remarks
CN-3807 External control board XVS-7000
CNI-43 SDI input board XKS-S8110
CNI-44 SDI input and FC connector board XKS-S8111
CNI-45A 12G-SDI Input board XKS-S8112
NET-28 IP input board XKS-T8110
NET-32 QSFP IP input and FC connector board XKS-Q8111
CNO-43 SDI output board XKS-S8165
CNO-44A 12G-SDI Output board XKS-S8167
NET-28A IP output board XKS-T8165
NET-32A QSFP IP output and FC connector board XKS-Q8166
NET-42A 100G input board XKS-C8111
NET-42B 100G output board XKS-C8166
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
1-7
