Sony XVS-9000 Service Manual

4-12. FP-301 Board
Preparation
1. Remove the front panel. (Refer to “4-2. Front Panel”)
Procedure
1. Remove the two screws, then remove the FP-301 board in the direction of the arrow.
PSW3 x 6
FP-301 board
Front panel
2. Install the removed parts by reversing the steps of removal.
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
4-25
