28
Step 3 Set IP address of the ETH port to be within the same network segment as that of the back-
ground monitoring system.
figure 5-2 Connection to PV background system
Default IP of the "ETH" IP:12.12.12.12.
- - End
5.5 Connection to Micro-SIM
Micro-SIM Card Requirements
• Size: 12mm × 15mm.
• Recommended SIM card provider: Telekom, Vodafone, or T-Mobile.
• Ensure that the Micro-SIM card has been properly configured the monthly data plan.
table 5-2 Monthly data required
Device Connected
Monthly Data Required
Inverters
Number of inverters × 25MB + 25MB
Number of inverters × 37.5MB + 37.5MB
Optimizers Number of optimizers × 0.52MB + 130MB
Meter and meteo station
The Micro-SIM card is not included in the scope of delivery.
5 Electrical Connection User Manual
