Parameter
Description
Reactive power direction*
Forward Direction: The reactive power direction of the in-
verter array displayed by the meter/transformer is the same
as the actual reactive power direction.
Direction Reverse: The reactive power direction of the in-
verter array displayed by the meter/transformer is opposite to
the actual reactive power direction.
Control cycle
Time interval of delivering dispatching instructions
Parameter range: 5~60s
Note: *Only when the control method is set to Closed-loop control, the parameter Select
energy meter / transformer is settable.
Step 4 After finishing parameter setting, click Save to save the operation.
- - End
8.3.2.3 Local Power Control
If reactive dispatching instruction or dispatching target value is used as dispatching input lo-
cally, the Reactive Control Mode is set to Local Power Control.
Step 1 Click “Power control→Reactive power” to enter the reactive power interface.
Step 2 Set the Reactive Control Modeto Local Power Control.
8 Grid Dispatching Function User Manual
