8.3.1.6 DRM mode
When using the digital signal at the DI port (DI1 ~ DI4) of the Logger1000 as the dispatching
input, set the active control mode to DRM mode.
Step 1 Click “Power control→Active power” to enter the active power interface.
Step 2 Set the active control mode to DRM mode and click Save.
- - End
8.3.1.7 Country mode
If the dispatching input must be the national power dispatching instruction, the Active Con-
trol Mode is set to Country mode.
Step 1 Click “Power control→Active power” to enter the active power interface.
Step 2 Set the active control mode to Country mode.
Step 3 Select Country and PPC type respectively from the drop-down lists, enter Forwarding
Modbus ID, and then click Save.
- - End
8.3.1.8 Disable Dispatching
Set the active control mode to Disable Dispatching if the Logger1000 is prohibited to per-
form active dispatching on the inverter.
Step 1 Click “Power control→Active power” to enter the active power interface.
Step 2 Set the active control mode to Disable Dispatching and click Save.
- - End
8.3.2 Reactive Power
8.3.2.1 Disable Output
If the grid company does not need the power plant to adjust the voltage at the grid-connec-
tion point, and the inverter does not need to cooperate with the grid for reactive power com-
pensation, the inverter keeps operating in the reactive-forbidden output state, and the
Reactive Control Mode is set to Disable Output.
Step 1 Click “Power control→Reactive power” to enter the reactive power interface.
Step 2 Set the Reactive Control Mode to Disable Output and click Save.
- - End
8.3.2.2 Remote Power Control
When the instruction source is IEC104 or MODBUS TCP protocol, set the Reactive Control
Mode to Remote power control.
