Sungrow Logger1000B User Manual

61
7.10.11.1 RS485
Step 1 Click “System→Port Parameter→RS485” to enter the corresponding interface.
Step 2 Click
to modify Baud Rate, Parity Bit, and Stop Bit.
Step 3 Click Save to save the information.
- - End
When the Logger1000 is connected to a device via the serial port, the Baud Rate,
Parity Bit, and Stop Bit of the serial port should be the same as those set for the
connected device, so as to ensure normal communication between the Log-
ger1000 and the connected device. The baud rate is 9,600bps, stop bit is 1, and
there is no parity bit by default. If EyeW485 is enabled, set the baud rate of the
corresponding COM port to 115,200.
7.10.11.2 EyeW485
Click “System →Port Parameter→EyeW485” to enter the corresponding interface, on
which users can configure the master and slave nodes of the EyeW485 and send related op-
eration instructions.
EyeW485–H
On this interface, uses can set the Country/Region, Frequency, and Array of the master
node.
table 7-10 EyeW485-H Parameter Description
Parameter
Description
Country/Region Select the country/region.
Frequency
Click Select Measuring Point(s) to select the frequency
point of the matched country/region.
Array
Select the array according to the color of the COM indicator
on the slave node.
After finishing the configuration, click Settings.
The frequency point of master and slave nodes can be configured simultaneously if the net-
working between master and slave nodes is finished. Click Select Measuring Point(s) to
enter the Frequency interface, check the frequency point of the matched country/region,
click Confirm, and click Configure Synchronization.
User Manual 7 WEB Interface
