Sungrow Logger1000B User Manual

35
7 WEB Interface
7.1 Running Requirements
Item Parameter
Browser
IE11 or later, Chrome65 or later, and Safari11 or
later
Min. resolution 1024*768
7.2 Login Steps
The Web interfaces provided in this document are for reference only, and the ac-
tual ones may differ.
Users of different types have different permissions. In the following, description is
given by using the O&M permission as an example.
Users can log into the Logger1000 via the Ethernet or WLAN (recommended).
7.2.1 WLAN Login
Step 1 Open the wireless network settings of the PC, search for the wireless network "SG-
A1234567890" of the Logger1000, and connect the PC to the wireless network of the Log-
ger1000 (without password).
"SG-A1234567890" is just used as an example. For actual wireless network, refer
to the S/N on the label attached to the front side of the Logger1000.
Step 2 Enter the IP address 11.11.11.1 of the Logger1000 in the PC address bar to enter the general
user login interface.
Step 3 Click the button Login in the upper right corner, enter the default password "pw1111", and
click Login, to enter the O&M user interface.
- - End

Sungrow Logger1000B Specifications

General

Brand	Sungrow
Model	Logger1000B
Category	Data Loggers
Language	English
