41
7.7 Device Monitoring
Click Device Monitoring to enter the corresponding interface.
Device information such as real-time values, DC data, initial parameter,operation parame-
ters, system parameters, protection parameter, power regulation parameters, general pa-
rameter, device instruction and device information can be viewed on this interface.
The device data will be cached for 7 days. In the case of network outage during
the operation of the device, the inverter data generated during the period of net-
work outage will be uploaded after the network service is back to normal. Please
contact SUNGROW if you want to check the data uploaded after the network out-
age event.
7.7.1 RealTime Values
Realtime information such as power generation, device state, and active power can be
viewed on this interface.
Step 1 Click “Device Monitoring→Realtime Values” to view the corresponding information.
Step 2 Click the button
to select the device type.
- - End
7.7.2 DC Info
Click “Device Monitoring→DC Info” to view the corresponding information.
On this interface, voltage and current information of multiple inputs of MPPTs and strings
can be viewed.
7.7.3 Initial Parameter
Click “Device monitoring→Initial Parameter” to enter the corresponding interface and set
initial parameters.
Select the meter, set PT Transformation Ratio, CT Transformation Ratio, Meter Reverse
Connection Enable and Access Type, click Save.
When the meter cable is connected reversed, but it is not easy to change the wir-
ing, the correct meter data can be obtained after opening the meter reversing ena-
ble switch.
The meter reversal function supports single-phase meters and three-phase me-
ters. Note that only the reverse connection of three phases is supported, and the
reverse connection of one or two of the three phases is not supported.
Select the inverter, initial parameters can be set in two manners: single setting and batch
setting.
User Manual 7 WEB Interface
