- - End
The default iSolarCloud station is Chinese Server. Users in mainland China se-
lect Chinese Server, users in Europe select European Server,users in Australia
select Australian Server,and users in other regions select the International
Server.
To ensure the Logger1000 can function properly, please complete the router
whitelist settings first. For details, see Router Whitelist Settings.
7.10.7 IEC104
Configure the IEC104 forwarding service for the Logger1000 on this interface.
• Server Mode
In the server mode, Logger1000 is used as a Server and connected to PC server to imple-
ment data transmission and instruction delivery.
Click “System→Transfer Configuration→IEC104” to enter the corresponding interface.
The local port is 2404.
• Client Mode
In the client mode, Logger1000 is used as a Client and connected to PC server to implement
data transmission and instruction delivery.
Step 1 Click “System→Transfer Configuration→IEC104” to enter the "Server" tab by default.
Step 2 Click Client to enter the corresponding tab.
- - End
7.10.7.1 White list setting
When the option Enable White List is not selected, and the default IP address is "0.0.0.0",
any background devices with valid IP address can access the Logger1000.
When the option Enable White List is selected, and specified IP address is entered, only
the device with the specified IP address can access the Logger1000.
7.10.7.2 Generate Point Table
Step 1 Turn on the switch of local port 2404.
Step 2 Click Generate Point Table, and default IEC104 point table will be automatically imported to
configuration file.
- - End
User Manual 7 WEB Interface
