Engine Mechanical: 1D-61
2) Remove the other bearings with the special tool.
Special tool
(C): 09913–70210 (Bearing installer set)
LT-F400/F left Crankcase
1) Remove the retainers.
2) Remove the balancer shaft bearing with the special
tool.
Special tool
(A): 09921–20240 (Bearing remover set)
3) Remove the other bearings with the special tool.
Special tool
(B): 09913–70210 (Bearing installer set)
LT-F400/F right crankcase
1) Remove the retainers.
2) Remove the drive shaft bearing with the special tool.
Special tool
(A): 09913–70210 (Bearing installer set)
(C)
I827H1140281-01
I827H1140282-02
(A)
I827H1140283-02
(B)
I827H1140284-02
I827H1140285-02
(A)
I827H1140306-01
