3D-2 Propeller Shafts:
LT-F400/F
FWD
FWD
1
2
3
6
4
(a)
(a)
(a)
5
I827H1340003-02
1. Front output shaft (LT-F400F) 4. Shim(-s) : 100 Nâ‹…m (10.0 kgf-m, 72.5 lb-ft)
2. Rear output shaft 5. Driven bevel gear : Apply grease.
3. Drive bevel gear 6. Shim(-s) : Do not reuse.
