5A-3 Automatic Transmission:
Reverse Gear
I827H1510003-01
1. Conrod 5. Reverse idle gear 9. Output driven gear/Drive bevel gear
2. Crankshaft 6. Reverse driven gear 10. Driven bevel gear/Output shaft
3. Drive V-belt 7. Reverse gear dog
4. Transfer input shaft 8. Output drive gear
