Suzuki LT-A400 Service Manual

0C-8 Service Data:
Wattage
Unit: W
Brake + Wheel
Unit: mm (in)
Generator coil resistance 0.3 – 1.5 Ω B – B
Generator no-load voltage
(When the engine is cold)
65 V (AC) and more at 5 000 r/min
Generator Max. output Approx. 225 W at 5 000 r/min
Regulated voltage 13.5 – 15.0 V at 5 000 r/min
Ignition coil primary peak voltage 180 V and more (+): Ground, (–): W/BI
Starter relay resistance 3 – 5 Ω
Starter motor brush length
Standard 10.0 (0.39)
Limit 6.5 (0.26)
Battery
Type
designation
YTX14-BS
Capacity 12 V 43.2 kC (12 Ah)/10 HR
Fuse size
Main 30 A
Power source 10 A
Headlight (HI) 10 A
Headlight (LO) 10 A
Taillight 10 A
Ignition 10 A
Fan 10 A
Item Specification Note
Item
Specification
P-17 Others
Headlight
HI 35 x 2 ←
LO 35 x 2 ←
Brake light/Taillight 21/5 ←
Speedometer light 1.7 ←
Reverse indicator light 3.4 ←
Neutral indicator light 3.4 ←
Engine oil temp. indicator light 3.4 ←
High beam indicator light 3.4 —
Reversing light 21 —
Item Standard Limit
Rear brake cable play 3 – 5 (0.12 – 0.20) —
Rear brake pedal free travel 20 – 30 (0.8 – 1.2) —
Brake disc thickness Front 3.3 – 3.7 (0.130 – 0.146) 3.0 (0.20)
Brake drum runout Front — 0.30 (0.012)
Brake disc I.D. Rear — 160.7 (6.33)
Master cylinder bore Front 14.000 – 14.043 (0.5512 – 0.5529) —
Master cylinder piston diam. Front 13.957 – 13.984 (0.5495 – 0.5506) —
Brake caliper cylinder bore Front 33.960 – 34.010 (1.3370 – 1.3390) —
Brake caliper piston diam. Front 33.878 – 33.928 (1.3338 – 1.3357) —
Brake fluid type DOT 4 —
Steering angle
Right 47° —
Left 47° —
Turning radius 3.1 m (10.2 ft) —
Toe-in (with 75 kg, 165 lbs) 10 ± 4 (0.39 ± 0.16) —
Chamber 0.3° —
Caster 3° —
Wheel rim size
Front 12 x 6.0 AT —
Rear 12 x 7.5 AT —
