Suzuki LT-A400 Service Manual

0C-10 Service Data:
Differential
Chassis
Oil pump drive gear bolt 80 8.0 58.0
Exhaust pipe nut 18 1.8 13.0
Exhaust pipe mounting bolt 23 2.3 16.5
Muffler mounting bolt 23 2.3 16.5
Muffler connecting bolt 23 2.3 16.5
Engine oil drain plug 23 2.3 16.5
Cooling fan thermo-switch 20 2.0 14.5
Engine oil temperature switch 23 2.3 16.5
Oil pressure regulator 23 2.3 16.5
Drive bevel gear nut 100 10.0 72.5
Driven bevel gear nut 100 10.0 72.5
Engine mounting nut
M8 40 4.0 29.0
M10 55 5.5 40.0
Engine mounting bracket bolt 28 2.8 20.0
Rear output shaft nut 100 10.0 72.5
Air cleaner box mounting bolt 7 0.7 5.0
Oil filter 20 2.0 14.5
Main oil gallery plug 23 2.3 16.5
Starter motor mounting bolt 10 1.0 7.0
Starter motor lead wire mounting bolt 7 0.7 5.0
Starter motor housing bolt 3.5 0.35 2.5
Recoil starter mounting bolt 10 1.0 7.0
Recoil starter center nut 12 1.2 8.5
Generator stator set bolt 11 1.1 8.0
CKP sensor mounting bolt 6 0.6 4.3
Generator lead wire clamp bolt 6 0.6 4.3
Speedometer gearbox bolt 10 1.0 7.0
Gear shift cam stopper nut 10 1.0 7.0
Item N⋅mkgf-mlb-ft
Front drive (Differential) gear oil drain plug 32 3.2 23.0
Front drive (Differential) gear oil level plug 8 0.8 6.0
Front drive (Differential) gear oil filler plug 35 3.5 25.5
Front drive (Differential) gear case mounting nut 45 4.5 32.5
Front drive (Differential) gear case cover bolt 23 2.3 16.5
Final gear case cover bolt 23 2.3 16.5
Final gear oil filler plug 33 3.3 24.0
Final gear oil level plug 10 1.0 7.0
Final gear oil drain plug 33 3.3 24.0
Final gear coupling nut 100 10.0 72.5
Final drive gear bearing lock-nut 80 8.0 58.0
Item N⋅m kgf-m lb-ft
Item N⋅m kgf-m lb-ft
Handlebar clamp bolt 26 2.6 19.0
Steering shaft holder bolt 23 2.3 16.5
Steering shaft nut 49 4.9 35.5
Steering knuckle pinch bolt 50 5.0 36.0
Tie-rod end nut 29 2.9 21.0
Tie-rod lock-nut 29 2.9 21.0
Front shock absorber mounting bolt (Upper) 55 5.5 40.0
Front shock absorber mounting nut (Lower) 60 6.0 43.5
Suspension arm pivot nut (Upper & lower) 65 6.5 47.0
Wheel hub nut
Front 110 11.0 79.5
Rear 121 12.1 87.5
Wheel set nut
Front 60 6.0 43.5
Rear 60 6.0 43.5
Front Brake air bleeder valve 6 0.6 4.5
