1D-8 Engine Mechanical:
18) Remove the muffler and exhaust pipe.
19) Remove the front differential mounting bolts and
slide the front differential assembly (19) forward.
Refer to “Front Drive (Differential) Assembly
Removal and Installation (LT-A400F, LT-F400F) in
Section 3B (Page 3B-4)”.
20) Remove the engine mounting bracket (20).
21) Remove the engine mounting bolts and nuts.
WARNING
!
Care should be taken not to drop the engine
accidentally when the engine mounting bolts
and nuts are removed.
22) Remove the engine from the right side.
I827H1140245-01
I827H1140246-01
I827H1140247-01
19
I827H1140248-01
20
I827H1140249-01
I827H1140250-01
I827H1140251-01
