AGL7 module removal and replacement
AGL7 module re
moval and replacement
This section
contains the instructions on how you can remove and replace the
customer replaceable parts of the AGL7 module.
CAUTION. To avoid damage to this module, do not expose it to sprays, liquids, or
solvents. Do not flex the c ircuit board if you remove the board from its mounting
shield. The circuit board can be damaged by flexing. The shield provides
necessary structural support to the circuit board.
Required tools
The following tools are required to perform the removal and replacement
procedures:
Table 4-3: Required tools for removal and replacement of AGL7 module
Name Description
Tektronix part
number
Screwdriver handle
Accepts Phillips-driver bits
#1 Phillips tip Phillips-driver bit for #1 size screw heads
#2 Phillips tip Phillips-driver bit for #2 size screw heads
Nut driver, 9/16 inch
deep socket
Nut d river for removing the BNC
connectors
Nut driver, 14 mm
Special nut driver for removing the BNC
connectors of older AGL7 modules
003-A041-00
How to replace the rear-panel connectors and chassis
It is usually not necessary to replace the r ear-panel connectors or chassis.
H
owever, if a connector or chassis becomes damaged, you can replace it.
4–18 TG8000 Multiformat Test Signal Generator Service Manual
