Module installation and removal
3. Use a screwdriv
er with a #1 Phillips tip to loosen the two screws of the blank
panel attached to the slot you want to use, and then pull it a way from the
instrument. Save the blank panel for future use. (See Figure 1-2.)
If you are installing a new module into a slot that already contains a module,
remove the existing module. (See p age 1-14, To remove a module.)
Figure 1-2: Removing the blank panel
CAUTION. Be careful not to damage the parts and cables inside of the module
when you insert the module into the mainframe.
1–12 TG8000 Multiformat Test Signal Generator Service Manual
