HD3G7 module replaceable parts list
HD3G7 module r
eplaceable parts list
This section
contains a list of the replaceable modules for the HD3G7 module.
Use this list to identify and order replacement parts. For parts ordering or
servicing information, see Parts ordering information or Module servicing in the
Mainframe replaceable parts list section of this manual. (See page 2-35.)
This section contains a list of the replaceable parts and modules for the HD3G7
module. Use this list to identify and order replacement parts.
Abbreviations
Abbreviations conform to American National Standard A NSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the HD3G7 module.
Table11-8: HD3G7module–replaceableparts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
11-5-1 116-1146-03 1
MODULE ASSEMBLY; HD3G7
-2 211-0408-00 8
SCR, ASSY, WSHR; 4-40 X 0.250, PNH, STEEL, ZINC FINISH, T-10 TORX DR,
SEMS
-3 878-0199-00 1
CIRCUIT BD SUBASSEMBLY; SDI INPUT; 389409500 WIRED
-4 878-0200-00 1
CIRCUIT BD SUBASSEMBLY; SDI OUTPUT; 389409600 WIRED
-5
131-M057-00 4
CONN, RF: PCB, FEMALE, BNC, 75 OHM, EDGE LAUNCH TYPE
-6 348-1944-00 1
GAP PAD 3000S30
-7
214-5166-00 1
HEATSINK, PCB TO CHASSIS
-8 441-2555-00 1
CHASSIS, MODULE
-9 333-4576-00 1
PANEL, REAR; SAFETY CONTROLLED
-10 214-4762-00 2
SPRING; CONICAL
-11 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-12 220-0497-00 4
NUT, PLAIN, HEX; .5-28 X .562 HEX, BRS, NI (NICKEL) PLATED
-13 210-1039-00 4
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-14 211-0101-00 3
SCREW, MACHINE; 4-40 X 0.25, FLH, 100 DEG, ZINC PLATED STEEL, T8
-15 348-A128-00 2.5
cm
SHLD GASKET, ELEK: FINGER TYPE, 5.1MM LX6.4MM W, BE-CU [97-645-02]
TG8000 Multiformat Test Signal Generator Service Manual 11–25
