Tektronix TG8000 Service Manual

AWVG7 module a djustment procedures
Required equipment
The following table lists the equipment required to adjust the output offset and
gain, frame timing and clock timing, and frequency response.
Table 7-1: Equipment required for AWVG7 module adjustment procedures
Item No. Minimum requirement Recommended equipment
TV signal generator platform
1
Tektronix TG8000
Oscilloscope
1
Bandwidth: 1 GHz or higher Function:
Mask testi
ng
Tektronix DPO70404
Digital multimeter 1
5 1/2 digit
s
FLUKE 8842A
Peak dete
ctor amplifier
1 Tektronix part number 015-0408-00 and
TM500 ser
ies power supply
Peak detector head 1 Tektronix part number 015-0413-00
Probe 2 X 10 Tektronix P6139A
75 Ω BNC cable
2 Length:
72 inches
Tektron
ix part number 012-0159-01
75 Ω BNC cable
1
5C-2V, 1 m
Belden
1694, MarkerTek 1694-B-B-3
75 Ω feed-through termination
1Tektro
nix part number 011-0103-02
75 Ω coaxial termination
1Tektr
onix part number 011-0102-03
BNC T connector
1Tektr
onix part number 103-0030-00
BNC female-to-dual banana
adapter
1Tekt
ronix part number 103-0090-00
BNC female-to-female
con
nector
1
Canare BCJ-J
Fl
at blade screwdriver for
adjusting C604B, C704B, and
C804B
1 Bit shape: 0.8X0.35 mm Murata KMDR060
TG8000 Multiformat Test Signal Generator Service Manual 7–3
