Tektronix TG8000 Service Manual

AVG7 module adjustment procedures
Required equipment
The following table lists the equipment required to adjust the output offset and
gain, frame timing and clock timing, group delay, frequency response, and
interchannel delay.
Table 6-1: Equipment required for the AVG7 module adjustment procedures
Item No. Minimum requirement Recommended equipment
TV signal generator platform
1
Tektronix TG8000
Test signal generator 1
Tektronix ATG7
Oscilloscope
1
Bandwidth: 1 GHz or higher Function:
Mask testing
Tektronix DPO70404 with TCA75 75 Ω
signal adapter
Digital multimeter 1
5 1/2 digits
FLUKE 8842A
Peak detector amplifier
1 Tektronix part number 015-0408-00 and
TM500 series power supply
Peak detector head 1 Tektronix part number 015-0413-00
Probe 2 X 10 Tektronix P6139A
75 Ω BNC cable
3 Length: 72 inches Te ktronix part number 012-0159-01
75 Ω BNC cable
1
5C-2V, 1 m
Belden 1694, MarkerTek 1694-B-B-3
75 Ω feed-through termination
1 Tektronix part number 011-0103-02
75 Ω coaxial termination
1 Tektronix part number 011-0102-03
BNC T connector
1 Tektronix part number 103-0030-00
BNC female to dual banana
adapter
1 Tektronix part number 103-0090-00
Flat blade screwdriver for
adjusting C604B, C704B, and
C804B
1 Bit shape: 2.2 × 0.4 mm Murata KMDR010
BNC female-to-female
connector
1
Canare BCJ-J
TG8000 Multiformat Test Signal Generator Service Manual 6–3
