Mainframe replaceable parts list
Module servicing
Modules can be s
erviced by selecting one of the following three options. Contact
your local Tektronix service center or representative for repair assistance.
Module exchange. In some cases you may exchange your module for a
remanufactured module. These modules cost significantly less than new modules
and meet the same factory specifications. For more information about the module
exchange pr
ogram, call 1-800-833-9200. Outside North America, contact a
Tektronix sales office or distributor; see the Tektronix Web site for a list of offices:
www.tektronix.com
Module repair and return. You may ship your module to us for repair, after which
we will return it to you.
New modules. You may purchase replacement modules in the same way as other
replacement parts.
Using the replaceable parts list
This section contains a list of the mechanical and/or electrical components that are
replaceable for the TG8000. Use this list to identify and order replacement parts.
The following table describes each column in the parts list.
Table 2-6: Parts list column descriptions
Column Column name Description
1
Figure & Index Number Items in this section are referenced by figure and index numbers to the exploded
view illustrations that follow.
2 Tektronix Part Number
Use this part number when ordering replacement parts from Tektronix.
3 and 4
Serial Number Column three indicates the serial number at which the part was first effective.
Column four indicates the serial number at which the part was discontinued. No
entries indicates the part is good for all serial numbers.
5
Qty This indicates the quantity of parts used.
6
Name & Description An item name is separated from the description by a colon (:). Because of s pace
limitations, an item name may sometimes appear as incomplete. Use the U.S.
Federal Catalog handbook H6-1 for further item name identification.
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the TG8000 mainframe.
2–36 TG8000 Multiformat Test Signal Generator Service Manual
