4.5 Lower Links - Hook Type Ball Ends
Whenever the hook-type ball ends are fitted, to attach the implement proceed as follows:
Procedure
1. Unlock the hook pulling the lever (A).
2. Raise the links until the hook ends engage
the link balls and lock into position.
3. To detach, rest the implement safely on the
ground, lift the catches and latch back as
above.
4. Move down the lower links and after having
detached the top link and any other
connections move forward.
GUID-C1BC5C94-F036-4F21-AC89-C223E7F7C4DF-low.png [Low]
Fig. 57
GUID-0DC5CE8A-D60B-411E-800A-35CF113B58DB [V2]
4. Maintenance
F Series 171
39940211 (555124)
