4. Engage the PTO switch (4), or the
mechanical PTO clutch lever (5).
5. Move from the operator's seat, and in less
than 5 seconds, engage the PTO switch (4),
or the mechanical PTO clutch lever (5) again.
NOTE:
If the PTO is on when you move from the
operator's seat, the PTO automatically stops.
GUID-845A5C55-F9FF-4ECE-8243-C29263D411E2-high.jpg [High]
Fig. 100
GUID-9FF4E4A9-F085-4399-AD2A-EE85A71B3244-high.jpg [High]
Fig. 101
3.2.9 PTO Warning Light Logic
WARNING:
The PTO Warning Light status depend of the engine rpm, ground drive PTO control (if
equipped) and PTO speed control.
All possible PTO control combinations are described in the following table with the correspondent Warning
Light status:
Ground PTO
control
PTO clutch
Control
Speed PTO
Control
Engine rpm
PTO warning light
status
Independent ON Neutral Independent 540+540E Flashing
Independent ON Independent <400 540+540E Flashing
OFF ON 540 >400 540 ON
OFF ON 540 E >400 540 E ON
OFF ON 1000 >400 1000 ON
OFF OFF Independent Independent All lights OFF
ON Independent Independent <400 540+540E Flashing
GUID-38CA0B15-EEE6-4001-A819-6B5995AB4442 [V1]
3. Operation
102 F Series
39940211 (555124)
