Adjust the steering wheel angle:
(D) Turn the knob (3), to unlock the steering
wheel.
(E) Set the steering wheel to the necessary
angle.
(F) Turn the knob (3), to lock the steering wheel
at the necessary angle.
NOTE:
Lock the steering wheel correctly, before you
drive.
GUID-50BE36E5-AD56-4D01-AE35-D6231A5D8C16-low.png [Low]
Fig. 27
3.1.5 Battery cut-o Switch
The battery cut-o switch is located on the rear
side of the tractor, close to the battery.
• To disconnect the battery, turn the switch (C) to
position (A) - OFF.
• To connect the battery, turn the switch (C) to
position (B) - ON.
GUID-809EE71A-19FE-4B1F-A9B6-65E47752A1BC-low.png [Low]
Fig. 28
IMPORTANT:
This vehicle is equipped with a battery cut-o switch that allows the battery to be disconnected from the
electric system.
The cut-o switch is not a safety switch and cannot be used to stop the engine.
Never use the battery cut-o switch when the engine is still running: switch o the engine and wait at
least 1 min before activating the cut-o switch to avoid serious damage to the vehicle electric/electronic
system. In addition, the voltage peaks that occur at the alternator are dangerous.
IMPORTANT:
Before turning the battery cut-o switch to the OFF position, wait at least 1 min from the last engine stop
(key-o). It allows the various control units to disconnect properly.
After turning the battery cut-o switch to the ON position, wait at least 10 sec before turning the ignition
key to start engine. It allows the various control units to operate correctly.
CAUTION:
To avoid shock and burns, disconnect the battery before servicing on any part of the
electrical system.
3.1.6 Instrument panel
GUID-1C47C75B-35FE-4E27-BE0F-82A3B7C980D5 [V1]
GUID-86736E7F-85AD-4890-A834-BFF138ADBD87 [V1]
