After finishing the procedure
WARNING:
Power take-o shafts and power take-
o driven implements can be
extremely hazardous; observe the
following important points:
• Remove PTO cap (A) only when
the PTO is to be used.
• As soon as PTO-driven implement
is removed, re-install cap over PTO
stub shaft.
NOTE:
Master shield (B) may be folded up when attaching
certain implements to the PTO, but it must be
lowered as soon as the implement is installed.
GUID-A06884C1-C3B4-44CF-9DC7-8E27DE72DD5C-low.png [Low]
Fig. 88
CAUTION:
Never operate PTO unless the master shield is in position.
DANGER:
Before attaching, adjusting or working on PTO-driven implements, disengage the PTO,
stop the engine, remove the key and apply the parking brake. DO NOT work under raised
implements.
Before engaging a PTO-driven implement that is attached to rear three point, ALWAYS carefully raise and
lower the implement using Position Control, checking for clearances, PTO shaft slide range, and
articulation.
Refer to Safety Instructions for important information.
The tractor can be fitted with one of three types of PTO:
• Single speed 540 rpm.
• Two speed 540/540E rpm.
• Two speed 540/1000 rpm.
IMPORTANT:
When operating PTO implements such as rotary mowers, hay balers, grinder-mixer, etc., the implement
must be equipped with an overrunning clutch or damage to PTO brake may occur.
DANGER:
DO NOT connect, disconnect or adjust PTO with the engine running.
DANGER:
As soon as the PTO implement drive shaft (shaft with universal joint (s)) is removed,
always install the PTO output shaft guard over tractor PTO shaft.
3. Operation
96 F Series
39940211 (555124)
