Vertiv Netsure User Manual

NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
[129]
 Over Voltage: Sets the converter Over Voltage alarm point.
 Over Current: Sets the converter Over Current alarm point.
 Converter Trim(24V): Temporarily sets the output voltage for all converters when the controller is in Manual mode. Setting
returns to original when controller is returned to the Auto mode.
 Converters LED Control: Temporarily sets whether or not a converter’s local power indicator blinks when the controller is
communicating with the converter when the controller is in Manual mode. Setting returns to original when controller is
returned to the Auto mode.
 Fan Speed Control: Sets the fan speed for all converters.
 Confirm Converter ID: After changing converter ID assignments, use this menu item to confirm the change. The only selection
is Yes. Once Yes is selected and confirmed, the ID setting of all converters is updated.
 Reset Converter IDs: Resets the converter IDs after they have been previously changed and confirmed. The only selection is
Yes. Once Yes is selected and confirmed, the NCU resets the converter IDs by reassigning ID numbers.
 Clear Converter Lost Alarm: Clears a converter lost alarm. The only selection is Yes. Once Yes is selected and confirmed, the
alarm clears.
 Clear All Converters Comm Fail: Clears an “All Converter Comm Fail” alarm. The only selection is Yes. Once Yes is selected and
confirmed, the alarm clears.
 Clear Converter Comm Fail: Clears all “Converter Comm Fail” alarms. The only selection is Yes. Once Yes is selected and
confirmed, the alarm(s) clears.
Solar Tab Programmable Parameter Descriptions
 Solar Converter Current Limit: Sets the output current limit point for all solar converters combined.
NOTE: Can only be made when the controller is in the "manual control" state. If the controller is set for "automatic" control, change the
“Auto/Manual State” setting first to the “Manual” setting.
 HVSD Limit: Sets the High Voltage Shutdown point for all solar converters.
 Restart on HVSD: Enables or disables the High Voltage Shutdown Restart feature for all solar converters.
 HVSD Restart Time: When the High Voltage Shutdown Restart feature is enabled and the output exceeds the high voltage limit,
the solar converters restart after this time period expires.
 Walk-In: Enables or disables the start-up walk-in feature for all solar converters.
 Walk- In Time: Sets the start-up walk-in time when the “Walk-In” setting above is set to enabled.
 Sequence Start Interval: Sets the sequence start interval (time period between starting each solar converter in the system).
 Solar Converter Trim: Temporarily sets the output voltage for all solar converters when the controller is in Manual mode.
Voltage can be increased or decreased from the existing Float Charge or Equalize Charge setting, depending which mode the
controller was in when set to "Manual". Setting reverts to original when controller is returned to the Auto mode.
 DC On/Off Control: Temporarily turns the DC output on or off for all solar converters when the controller is in Manual mode.
Setting returns to original when controller is returned to the Auto mode.
 Solar Converter LED Control: Temporarily sets whether or not a solar converter’s local power indicator blinks when the
controller is communicating with the solar converter when the controller is in Manual mode. Setting returns to original when
controller is returned to the Auto mode.
 Fan Speed Control: Sets the fan speed for all solar converters.
