NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
DO (relay) Tab
Allows you to use the relay test feature.
o Relay Test: Sets the Relay Test feature to Automatic, Manual, or Disabled. Refer to “Using the Relay Test Feature” on page
28.
o Relay Test Time: Sets the Relay Test Time for the Automatic Relay Test feature.
Allows you to set the relay active or not active.
o Temporarily sets the relay active or not active when the controller is in Manual mode. Setting reverts to original when
controller is returned to the Auto mode. Refer to “Manually Forcing Relays” on page 23.
Allows you to change the relay signal full name (name displayed in the Web Interface menus).
Figure 93. DO (Relay) Tab
